PY-107 為壓克力型紫外線硬化透明感壓膠，乾燥速度快、中高黏度、流平性佳、黏性佳、高溫不脫膠，主要用于晶圓或玻璃減薄膠帶。
PY-107 is an acrylated system for UV-curable clear pressure adhesive, it exhibit high curing speed, medium high viscosity, good leveling, good tacky properity, excellent adhesion higher temperture, especially for wafer or glass decrease thickness PSA.
規(guī)格(Specifications):
(1).外觀(appearance): 透明淡黃色(light yellow liquid)
(2).組成(composition): 丙烯酸酯(Acrylate)
(3).黏度(Viscosity): 1600-2300 cps/25oC
(4).有效成分%(Active Component %): ca 40 %
(5).溶劑(Slovent): 調(diào)合溶劑(Mix Solvents)
(6).乾燥速度(Curing Speed): 150-160 oC oven 2-4 min
Then 400-600 mJ/cm2/UV Lamp(80W/cm)
建議使用(Suggest Uses):
PY-107 以滾輪涂佈機(Kama)上膠涂于 PET 底材上, 厚度控制在 50um, 經(jīng)由熱烘(150-160 oC)去除溶劑(約 2-4 分鐘), 再經(jīng)過 UV 燈(80/cm; 365nm)照射(400-600mJ/cm2), 貼上保護膜收卷。
PY-107 Use roller-to-roller(Kama) coating on the PET substrate, controlled the thickness(50um), then pass the oven(150-160 oC) to remove the solvents(2-4 min), after UV cure(80/cm; 365nm), 400-600 mJ/cm2, cover with protecting film.
包裝(Package): 120 kg/drum
儲存期限(Storage):
置于陰涼處，不可直接接觸熱源、空氣及陽光，可保存三個月。
Storage must in a cool, shaded; away from sources of direct heat, air and sunlight is 3 months maximum.
|
